X-LAB RS5

The RS5 delivers the X-LAB riding experience in a versatile and approachable form.
Built with durable X6 aluminum alloy and a semi-integrated cockpit, it offers reliable performance, confident handling, and lasting comfort.
Whether you're discovering the sport or simply enjoying the ride, the RS5 is designed to make every kilometre feel smooth, responsive, and rewarding.

Integrated Design, Rea-World Road Bike
RS5 brings the X-LAB fluent design and engineering language to an alloy platform, with a clean cockpit integration paired with Shimano 105 performance so the bike looks like it belongs far above its category.

Alloy Done the X-LAB Way
A precision-engineered alloy frame delivers the kind of durability and the ride quality riders trust. The RS5 is built for long rides, daily commutes, and everything in between.

Power + Security, Standard
Branta's in-house alloy crankset integrates a power meter and Find My Tech, turning the RS5 into a smarter bike to train on, track, and own, without asking riders to bolt on costly extras.

Technical Specifications

FRAME
XDS X6 Alloy Frame, UDH Compatible

FORK
XDS Carbon Fork, 100x12mm Thru-axle

HANDLEBAR / STEM
Branta Alloy Integrated

SEATPOST
XDS Carbon Seatpost, Aero Profile

REAR DERAILLEUR
Shimano 105 RD-R7100

FRONT DERAILLEUR
Shimano 105 FD-R7100

SHIFTERS
Shimano 105 ST-R7120

BRAKES
Shimano 105 BR-R7170

CASSETTE
Shimano 105 CS-R7101, 11-34T

CRANKSET
Branta Alloy Power Meter Crankset, 52-36T,
24mm Steel Spindle, Apple Find My Anti-Theft Technology

BOTTOM BRACKET
BSA 24mm

ROTORS
Branta PN28, F:160 R:160mm

CHAIN
Shimano CN-M7100

WHEELSET
Branta A35 SL, Alloy Rims

TIRES
Branta R332, 700x32C, 60TPI
Max Tire Clearance: 38C

SADDLE
Branta R302, Steel Rails

WEIGHT
9.54 kg / 21.03 lbs (Size L)

SIZE OPTIONS
XS / S / M / L / XL

*Continuous Product Improvement
Innovation never stands still. As part of our commitment to building the best possible bicycles, X-LAB reserves the right to update specifications, components, colors, and other product details at any time without notice. We make every effort to keep our published specifications current, but minor variations may occur between production batches. Please contact your local X-LAB dealer if you would like to confirm the latest specifications before purchase.

Basic geometry

Component geometry
