Overview

More Juice, No Excuse

The Moterra packs massive power, range, and silky suspension, handling rugged terrain like a luxury off-roader. Built to go further-faster.

Model Description

A masterclass in capability. The Moterra 2 features a new, lightweight, full carbon frame with 150mm travel and a hard-charging 160mm RockShox Zeb Select fork for pinpoint handling. A blended Shimano XT/CUES U8000 drivetrain and Magura MT5 brakes combine with Bosch's most powerful CX motor and 800Wh battery to extend every ride beyond expectation. Agile, composed, and ever-ready to push the limits of exploration.

What it's for

Endless spins, uphill wins, and permanent grins on all kinds of trails, from the mild to the wild

Highlights

- A lightweight carbon fiber frame - Proportional Response size-specific suspension, tuned for specifically for the air shock and 29' wheels
- Bosch's most powerful system - Performance CX motor and 800Wh battery. Incredibly natural power delivery and huge range
- Smooth and rugged RockShox suspension - 160mm ZEB Select 38 fork and Deluxe Select+ air shock
- Light and durable WTB ST i30 Tough rims, 30mm inner width, with Shimano hubs and Continental Kryptotal tires
- Flawless shifting from Shimano's high-end XT / CUES U8000 LinkGlide blended drivetrain
- Powerful, controllable stopping from Magura's MT5 4-piston stoppers with 203mm rotors

SPECS

- Frame - Moterra SL Carbon, 150mm travel, Proportional Response Tuned Suspension, FlexPivot Chainstay, direct mount internal battery, engineered plastic skid plate, 55mm chainline, internal cable routing, 29' FlipChip, 148x12mm Maxle thru-axle, UDH hanger, 200mm native post mount brake, angle adjust headset
- Fork - Fox Performance 36, 160mm travel, Grip Damper, 3-position adjust, 15x110mm Kabolt thru-axle, tapered steerer, 44mm offset

- Headset - Acros Adjustable Angle (1.2degree)

- Rear Shock - Fox Float X Performance Elite, 2 pos adj, EVOL LV, 210x55mm

- Drive Unit - Shimano EP801, 85Nm, Custom Tuned, Eco, Trail 1, Trail 2, Boost Modes

- Battery - Custom 601Wh battery

- Charger - Custom 4A

- Display - Shimano SC-EM800 Cycle Computer, Bluetooth LE Compatible

- Rear Derailleur - Shimano XT

- Shifters - Shimano XT, 12-speed

- Chain - Shimano XT, 12-speed

- Crank - e*thirteen e*spec Plus, 160mm (S/M), 165mm (L/XL), 34T

- Rear Cogs - Shimano XT, 10-51, 12-speed

- Brakes - Magura MT5 4-piston hydraulic disc, 203/203mm Storm HC 6-bolt rotors

- Brake Levers - Magura MT5 hydraulic disc

- Rims - WTB KOM Trail i30, 30mm inner width, TCS tubeless ready

- Spokes - DT Swiss Champion

- Tire Size - 2.5

- Wheel Size - 29 / 27

- Hubs - (F) Formula DC-71132h, 15x110mm / (R) DT Swiss 370 Hybrid LN Ratchet System, 32h, 12x148mm

- Tires - (F) Maxxis DHF, 29x2.5", 3C, EXO+, tubeless ready / (R) Maxxis Dissector, 27.5x2.4", 3C, EXO+, tubeless ready

- Handlebar - Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8degree sweep, 5degree rise, 800mm

- Stem - Cannondale 1, 7075 Alloy, 1-1/8", 35mm, 0degree

- Grips - Cannondale Taper Ridge

- Saddle - Fizik Terra Ridon X5, Mobius S alloy rail

- Seatpost - Cannondale DownLow Dropper, internal routing, 31.6, 150mm (S), 170mm (M-L), 200mm (XL)

- Extra 1 - Tubeless valves


Please note that, based on component availability and other factors, specifications are subject to change without notice.
